PVC foam board machine
PVC foam board extrusion machine
PVC foamed board belongs to the new environmental protection material, called no defect board in foreign countries, and the double post, no oil leakage, no water seepage, scratch resistant, also called blister board, base material of density board, surface by vacuum blister or adopt a seamless and PVC film pressure molding process.
Production Application
PVC foamed board belongs to the new environmental protection material, called no defect board in foreign countries, and the double post, no oil leakage, no water seepage, scratch resistant, also called blister board, base material of density board, surface by vacuum blister or adopt a seamless and PVC film pressure molding process, green non-polluting, renewable, is the ideal alternative ambry materials, and the people life more convenient, the most suitable. Door plate in normal size without edge, waterproof, moisture-proof, hardness and flexibility.
Advantages
PVC board has excellent chemical stability, corrosion resistance, high hardness, high strength, anti-uv (aging resistance), fire resistance and flame retardant (with self-extinguishing), reliable insulation performance, smooth surface, not water absorption and deformation, easy processing and other characteristics
instruction
| Name of Commodity 380V .3P.50HZ |
| PVC WPC FOAM BOARD PRODUCTION LINE From NO1-8 1.automatic feeding system 2.SJSZ80/156 conical twin screw extruder 3. T -die mould ( L2450, W1220,T:5-25mm) 4.cooling calibration platform -4 couples calibrators Mould temperature controller 2 sets 5.cooling support 6.eight pairs rubber rollers traction with Trimming and dust collector 7. cutting machine 8. Automatic discharge and stacker /robert We supply free formula and full technical data support |
| NO | INSTRUCTION | SPECIFICATION |
| 2．1 | RAW MATERIAL | PVC Add auxiliary materials |
| 2．2 | BOARD SIZE | 5-25×1220 |
| 2．3 | Line speed | 0.7-1m/min |
| 2．4 | MAX OUTPUT | 350-500kg/h |
| 2．5 | MACHINE SIZE | 26000×2200×2900 L×W×H |
| 2．6 | WEIGHT | 35t |
| 2．7 | Total installed power | 175kw |
| 2．8 | Actual energy consumption power | 11kw |
| 2．9 | Gas consumption | 0.4m3/min |
| 2．10 | pressure | 0.8mpa |
| 2．11 | Water circulation | 0.4 m3/min |
| 2．12 | VOLTAGE | AC380V±10%50HZ |
| 2．13 | WATER | Industrial water, free of impurities, filtered, water pressure: 0.4MPa, water temperature: 15-25 ℃. |
| 2．14 | work environment | 0-40℃ |
Post time: Mar-29-2023
